In every piping system there are corners and turns — that’s why MultiGol angles are among the most common fittings in pressurized piping. Golan Industries offers 90° and 45° angles in all diameters, designed for MultiGol systems, with easy alignment and high durability for years to come.
Quick Summary
- 90° and 45° – the two most common angles in pressurized piping
- Compatible with all MultiGol diameters – 16, 20, 25, 32 mm
- Easy pressing – fast, reliable connection without welding
- High-pressure resistant – suitable for hot and cold water piping
- Quality material – reinforced PPSU/PP body
- Connects with fittings – part of the Golan MultiGol system
When do you use 90° and when 45°?
The choice between a 90° angle and a 45° angle depends on the site conditions:
90° angle – for sharp turns, usually in room corners, around walls, or anywhere you need an exact 90-degree corner. This is the most common angle in indoor piping.
45° angle – for gradual turns, when you need to reach a point that isn’t straight, but also doesn’t require a full 90° corner. Two 45° angles equal one 90° corner — with less pressure loss along the way.
How do you connect a MultiGol angle using the press method?
The MultiGol system works with Press-Fit — cold pressing without heat and without welding:
1. Cut the pipe straight with a pipe cutter.
2. Deburr the end — use a reamer to open up the pipe diameter at the end.
3. Insert — place the pipe end into the angle up to the depth mark.
4. Press — use the dedicated MultiGol pressing tool and press until fully closed.
5. Check — verify there are no leaks at full pressure.
📋Calculating the number of angles for a project
Map the pipe route
Mark on the apartment plan every place where the pipe turns 90° or 45°.
Count each type separately
Count how many 90° angles and how many 45° angles you’ll need. Add 10% as a safety margin.
Choose the correct diameter
Make sure the angle diameter matches your pipe diameter — 16, 20, 25, or 32 mm.
Order together with the pipes
Order all the fittings together to save time and shipping costs.
Do not connect different types of angles
MultiGol angles are designed only for Golan MultiGol pipes. Connecting them to competing pipes may cause leaks and void the warranty.
Recommended products
Conclusion
Golan MultiGol angles — 90° and 45° — provide a fast, reliable solution for every corner in pressurized piping. With the easy press method and high-quality materials, you can complete any piping project in a short time with complete reliability.
